| Reach Specifications | |
| Platform Height – Elevated – Lowered |
12.19 m 1.75 m |
| Platform Railing Height | 1.10 m |
| Overall Height – Rails Up | 2.81 m |
| Overall Height – Rails Lowered | 2.0 m |
| Platform Size | 1.65 x 2.92 m |
| Platform Extension | 91 cm |
| Overall Width | 1.75 m |
| Overall Length | 3.1 m |
| Wheelbase | 2.3 m |
| Ground Clearance | 20 cm |
| Platform capacity | 362 kg |
| Capacity on Platform Extension | 113 kg |
| Lift/Lower Time | 54/50 sec |
| Maximum Drive Height | 9.14 m |
| Weight | 4790 kg |
| Ground Bearing Pressure | 4.29 / cm2 |
| Chassis | |
| Drive Speed – Elevated | 0.64 kmph |
| Drive Speed – Lowered | 4.8 kmph |
| Gradeability (2 WD/4WD) | 35%/45% |
| Turning Radius (inside) | 2.29 m |
| Turning Radius (Outside) | 4.72 m |
| Tire Size / Type | 240/55-17.5 Non Marking |
| Brakes | Spring Applied Hydraulically Released Discs |
| Power Source | |
| Batteries | 8 x 6 V, 370 amp-hr |
| Charger | 21 Amp, Automatic SCR Charger |
| Electric Pump Motor | Series Wound |
| Drive Motors | Two 5.5 hp Shunt Wound |
| Pump | Single Section Gear Pump |
| Hydraulic Reservoir | 32.18 L |
| Generator Set (Multi-power options) |
Fully Automatic , 45 Amp Kubota, 6 hp Air-Cooled Engine
|
| Engine Fuel Tank | 15.14 L |
