| Specifications | Z135/70 |
| Working height maximum | 43.15 m |
| Platform height maximum | 41.15 m |
| Horizontal reach maximum – riser extended Horizontal reach maximum – riser retracted |
18.03 m 21.26 m |
| Up and over clearance maximum – Riser extended Riser retracted |
23.01 m 9.91 m |
| Below ground reach | 5.87 m |
| Platform length – 8 ft model / 6 ft model | 0.91 m / 0.76 m |
| Platform width – 8 ft model / 6 ft model | 2.44 m / 1.83 m |
| Height stowed | 3.07 m |
| Length stowed | 12.93 m |
| Width – axles extended Width – axles retracted |
3.94 m 2.46 m |
| Wheelbase – axles extended Wheelbase – axles retracted |
4.11 m 4.72 m |
| Ground clearance – center | 0.51 m |
| Productivity | |
| Lift capacity | 272 kg |
| Platform rotation | 160° |
| Vertical jib rotation | 110° |
| Turntable rotation | 360° continuous |
| Turntable tailswing – axle extended riser up Turntable tailswing – riser down |
0.79 m 4.27 m |
| Drive Speed – stowed Drive Speed – raised |
4.8 km/h 1.1 km/h |
| Lift speed to full height | 96 sec |
| Gradeability – stowed | 45% |
| Inside turning radius – axles extended Inside turning radius – axles retracted |
2.29 m 5.51 m |
| Outside turning radius – axles extended Outside turning radius – axles retracted |
5.64 m 7.77 m |
| Controls | 12 V DC proportional |
| Tires | 445/65 D22 18 ply foam filled |
| Power | |
| Power source |
Deutz Diesel TD 2011 LO4i 4-cylinder turbo diese, 74 h (55 kw)
Perkins Diesel 804-33T 4-cylinder turbo diesel, 83 hp (62 kw) |
| Auxiliary power unit | 12 V DC |
| Hydraulic tank capacity | 246.1 L |
| Fuel tank capacity | 151.4 L |
| Weight | 20366 kg |
| Standard Compliance |
ANSI A92.5, CSA B354.4, CE Compliance, AS 1418.10
|
