Ultracompact – The ULTRACOMPACT SIZE provides high maneuverability at the various job sites
Stable & Powerful Travelling – Glay coloured rubber crawler allows stable, powerful travelling and preventing marking on the floor.
Simple and Smooth Operations System – Proportional travelling and steering control system.
| MODEL SPECIFICATIONS | ||
| Model | RM04B | |
| BASKET | ||
| Platform Capacity | 200 kg | |
| Platform Height | Max 3.8m / Min 0.54m | |
| LIFT & LOWER SYSTEM | ||
| Type | 3 stage synchronized telescopic action | |
| Lifting Speed | 3.3m / 20 seconds (with 200 kg load) | |
| Lower Speed | 3.3m / 18 seconds (with 200 kg load) | |
| TRAVEL DEVISE | ||
| Speed | 0-2.0 km/hr (High speed mode) | |
| Gradeability | 20 degree (with 80 kg load) | |
| POWER SOURCE | ||
| Voltage | DC24V | |
| SAFETY DEVICE | ||
| Hydraulic safety equipment. Travelling warning alarm. Lift and lower warning alarm. Travelling & lifting limiting system. Overload prevention system. Emergency stop switch, Foot switch Operation level guard, Battery charger cable protection equipment. |
||
