| Specifications | S60 | S65 |
| Working height maximum | 20.30 m | 21.80 m |
| Platform height maximum | 18.30 m | 19.80 m |
| Horizontal reach maximum | 15.48 m | 17.10 m |
| Below ground reach | 1.70 m | 2.72 m |
| Platform length – 8 ft model 6 ft model |
0.91 m 0.76 m |
0.91 m 0.76 m |
| Platform width – 8 ft model 6 ft model |
2.44 m 1.83 m |
2.44 m 1.83 m |
| Height stowed | 2.72 m | 2.72 m |
| Length stowed | 8.51 m | 9.50 m |
| Length – transport (jib tucked under) | —-– | 7.60 m |
| Width (with standard tires) | 2.49 m | 2.49 m |
| Wheelbase | 2.50 m | 2.50 m |
| Ground clearance – center | 0.37 m | 0.37 m |
| Productivity | ||
| Lift capacity | 227 kg | 227 kg |
| Platform rotation | 160 degree | 160 degree |
| Vertical jib rotation | —- | 135 degree |
| Turntable rotation | 360 degree | 360 degree |
| Turntable tailswing | 1.22 m | 1.22 m |
| Drive Speed – 2WD stowed | 6.4 km/h | 6.4 km/h |
| Drive Speed – 4WD stowed | 4.8 km/h | 4.8 km/h |
| Drive speed – raised or extended | 1.1 km/h | 1.1 km/h |
| Gradeability – 2WD – stowed | 30% | 30% |
| Gradeability – 4WD – stowed | 45% | 45% |
| Turning radius – inside | 2.36 m | 2.36 m |
| Turning radius – outside | 5.54 m | 5.72 m |
| Controls | 12 V DC proportional | |
| Tires – RT Lig | 355/55d 625 | |
| Power | ||
| Power Source | Ford DSG-432 4 cylinder gas/LPG 75 hp (56 kw) Deutz D2011L03i 3 cylinder diesel 46 hp (34.3 kw) Perkins 404D-22 4 cylinder diesel 51 hp (38jw) |
|
| Auxiliary power unit | 12 V DC | 12 V DC |
| Hydraulic tank capacity | 170 L | 170 L |
| Fuel tank capacity | 132 L | 132 L |
| Weight | ||
| 2WD | 9308 kg | 10024 kg |
| 4WD | 9385 kg | 10102 kg |
| Standard Compliance | ANSI A92.5, CSA B354.4 CE Compliance, AS 1418.10 | |
